BRIGHT LC588 S
BRIGHT LC588 S
Concentrate on truck tire service for 15 years, non-stop
improving and updating, Now it becomes professional
equipment for truck and bus tires.
improving and updating, Now it becomes professional
equipment for truck and bus tires.
1600 MM
14" - 26"
1000 MM
130 - 150 bar
BRIGHT LC588 S
Concentrate on truck tire service for 15 years, non-stop
improving and updating, Now it becomes professional
equipment for truck and bus tires.
Technical Data
Rim Diameter
14” - 26” inch
Rim width
1000 mm
Max wheel diameter
1600 mm
Hydraulic Power
130 - 150 bar
Hydraulic Station Motor Power
1.5KW 380V/3PH 50HZ
Main Shaft Motor Power
1.8KW 380V/3PH 50HZ
Noise
＜75dB
Packing dimensions
2100x1650x930 mm
Net weight
561 kg
Gross weight
739 kg
Loading in 20/40 Ft. container
6/14 sets
Adopted hydraulic control system, reliable rim clamping, move stable. Hydraulic pump station adopted imported components with good stability .
Meet CE requirement, totally safe during operation
Lifting arm cylinder is center supported , bear pressure average
Movable operating station can be fully observed during operation to prevent danger by misoperation
The gearbox is made of aluminum alloy die casting, with light weight, beautiful appearance, high intensity and good sealing performance.
The electric cabinet adopted CE level protection standard.
Lifting arm and the base are made of strengthened and thickened metal, with high intensity.
Lifting arm cylinder equipped safety protection device to increase the safety of operation.
